Underground mining solutions

Built for the demands below.

Equipment and spare parts, specified around your operation.

Explore equipment Discuss your requirements

Representative visualization of a red underground mining truck with an enclosed operator cab — Underground mining trucksEnclosed operator cab · Representative visual

Equipment range

Choose the equipment. Define the possibilities.

A focused range for underground loading, haulage and mine support.

Representative yellow diesel LHD loader visualization

Diesel LHD Loaders

0.5–6 m³ bucket capacity

Compact to high-capacity scooptrams for underground loading and hauling. Specify tunnel clearance, working gradient and target bucket capacity.

View diesel range

Red electric-drive underground LHD loader

Electric LHD Loaders

0.6–6 m³ bucket capacity

Electric-drive loaders for operations with suitable underground power infrastructure. Confirm the power supply, cable requirements and operating layout.

View electric range

TU-40 underground mining truck with enclosed cab, from the catalogue

Underground Mining Trucks

6–40 t payload range

Underground haulage options matched to your mine layout and production needs. Start with payload, haul distance, gradients and turning clearance.

View truck range

Rock Breaking & Scaling

Mobile and fixed rock breakers, plus scaling vehicles.

Utility Vehicles

Personnel, materials and service transport underground.

Built around the way you work

From the working face
to the next shift.

uniBesco connects underground equipment and spare parts with the practical requirements of your operation. Start with the task, then define capacity, clearance and configuration.

Discover uniBesco →

Load & haul

Match bucket volume and payload to tunnel dimensions, haul distances and production needs.

Develop & support

Specify breakers, scaling equipment and service vehicles around the working envelope and daily tasks.

Maintain & renew

Identify replacement parts and discuss customization or overhaul requirements for your existing fleet.

Complete equipment catalogue

Every task. The right specification.

49 catalogue models, across five equipment families. Compare the essentials and open a model for its full technical details.

Find your model

All models shown

Diesel LHD Loaders

Loading and hauling with diesel-powered scooptrams, from compact access to larger production headings.

15 models

Diesel underground LHD loader

TC-0.6

0.5–0.6Bucket volume (m³)55Engine power (kW)

All specifications ＋

Rated load (t): 1.2
Bucket volume (m³): 0.5–0.6
Empty weight (t): 4.5
Shoveling force (kN): 35
Tractive force (kN): 40
Engine power (kW): 55
Full-load speed (km/h): 0–9
Length (mm): 4880
Width (mm): 1100
Height (mm): 1825 (adjustable)

Product details →Enquire

Diesel underground LHD loader

TC-0.6CB

0.6Bucket volume (m³)66Engine power (kW)

All specifications ＋

Rated load (t): 1.2
Bucket volume (m³): 0.6
Empty weight (t): 5.28
Shoveling force (kN): 35
Tractive force (kN): 40
Engine power (kW): 66
Full-load speed (km/h): 0–14 (2 gears)
Length (mm): 5250
Width (mm): 1100
Height (mm): 1840

Product details →Enquire

Diesel underground LHD loader

TC-0.75

0.75Bucket volume (m³)55Engine power (kW)

All specifications ＋

Rated load (t): 1.5
Bucket volume (m³): 0.75
Empty weight (t): 6.8
Shoveling force (kN): 42
Tractive force (kN): 45
Engine power (kW): 55
Full-load speed (km/h): 0–9.5
Length (mm): 5570
Width (mm): 1250
Height (mm): 1920 (adjustable)

Product details →Enquire

Diesel underground LHD loader

TC-0.6C

0.6Bucket volume (m³)55Engine power (kW)

All specifications ＋

Rated load (t): 1.2
Bucket volume (m³): 0.6
Empty weight (t): 4.8
Shoveling force (kN): 35
Tractive force (kN): 40
Engine power (kW): 55
Full-load speed (km/h): 0–9
Length (mm): 5250
Width (mm): 1100
Height (mm): 1840

Product details →Enquire

Diesel underground LHD loader

TC-1A

1Bucket volume (m³)55Engine power (kW)

All specifications ＋

Rated load (t): 2
Bucket volume (m³): 1
Empty weight (t): 7
Shoveling force (kN): 45
Tractive force (kN): 55
Engine power (kW): 55
Full-load speed (km/h): 0–9.5
Length (mm): 5570
Width (mm): 1405
Height (mm): 1920

Product details →Enquire

Diesel underground LHD loader

TC-1CB

1Bucket volume (m³)66Engine power (kW)

All specifications ＋

Rated load (t): 2
Bucket volume (m³): 1
Empty weight (t): 7.5
Shoveling force (kN): 45
Tractive force (kN): 60
Engine power (kW): 66
Full-load speed (km/h): 14
Length (mm): 6130
Width (mm): 1340
Height (mm): 1970

Product details →Enquire

Diesel underground LHD loader

TC-1C

1Bucket volume (m³)55Engine power (kW)

All specifications ＋

Rated load (t): 2
Bucket volume (m³): 1
Empty weight (t): 7
Shoveling force (kN): 40
Tractive force (kN): 50
Engine power (kW): 55
Full-load speed (km/h): 0–9.5
Length (mm): 5700
Width (mm): 1405
Height (mm): 1920

Product details →Enquire

Diesel underground LHD loader

TC-2C

2Bucket volume (m³)84Engine power (kW)

All specifications ＋

Rated load (t): 4
Bucket volume (m³): 2
Empty weight (t): 13
Shoveling force (kN): 90
Tractive force (kN): 100
Engine power (kW): 84
Full-load speed (km/h): 0–20
Length (mm): 7060
Width (mm): 1840
Height (mm): 1960

Product details →Enquire

Diesel underground LHD loader

TC-200CF

2–2.5Bucket volume (m³)84Engine power (kW)

All specifications ＋

Rated load (t): 4–5
Bucket volume (m³): 2–2.5
Empty weight (t): 13
Shoveling force (kN): 80
Tractive force (kN): 100
Engine power (kW): 84
Full-load speed (km/h): 0–20
Length (mm): 7060
Width (mm): 1840
Height (mm): 1960

Product details →Enquire

Diesel underground LHD loader

TC-300

3Bucket volume (m³)165Engine power (kW)

All specifications ＋

Rated load (t): 6
Bucket volume (m³): 3
Empty weight (t): 18
Shoveling force (kN): 100
Tractive force (kN): 120
Engine power (kW): 165
Full-load speed (km/h): 0–20
Length (mm): 8650
Width (mm): 2260
Height (mm): 2170

Product details →Enquire

Diesel underground LHD loader

TC-306

3Bucket volume (m³)160Engine power (kW)

All specifications ＋

Rated load (t): 6
Bucket volume (m³): 3
Empty weight (t): 18.5
Shoveling force (kN): 100
Tractive force (kN): 150
Engine power (kW): 160
Full-load speed (km/h): 0–20
Length (mm): 8550
Width (mm): 2150
Height (mm): 2057

Product details →Enquire

Diesel underground LHD loader

TC-200D

1.6Bucket volume (m³)84Engine power (kW)

All specifications ＋

Rated load (t): 3.2
Bucket volume (m³): 1.6
Empty weight (t): 12.5
Shoveling force (kN): 80
Tractive force (kN): 100
Engine power (kW): 84
Full-load speed (km/h): 0–18 (3 gears)
Length (mm): 6630
Width (mm): 1695
Height (mm): 1690

Product details →Enquire

Diesel underground LHD loader

TC-614

6Bucket volume (m³)256Engine power (kW)

All specifications ＋

Rated load (t): 14
Bucket volume (m³): 6
Empty weight (t): 25
Shoveling force (kN): 220
Tractive force (kN): 240
Engine power (kW): 256
Full-load speed (km/h): 0–25 (4 gears)
Length (mm): 10370
Width (mm): 2880
Height (mm): 2920

Product details →Enquire

Diesel underground LHD loader

TC-307

3Bucket volume (m³)165Engine power (kW)

All specifications ＋

Rated load (t): 7
Bucket volume (m³): 3
Empty weight (t): 19
Shoveling force (kN): 120
Tractive force (kN): 175
Engine power (kW): 165
Full-load speed (km/h): 0–20 (4 gears)
Length (mm): 8750
Width (mm): 2150
Height (mm): 2279

Product details →Enquire

Diesel underground LHD loader

TC-410

4Bucket volume (m³)220Engine power (kW)

All specifications ＋

Rated load (t): 10
Bucket volume (m³): 4
Empty weight (t): 23.5
Shoveling force (kN): 180
Tractive force (kN): 200
Engine power (kW): 220
Full-load speed (km/h): 0–25 (4 gears)
Length (mm): 9191
Width (mm): 2647
Height (mm): 2385

Product details →Enquire

Electric LHD Loaders

Electric-drive loaders for underground operations with suitable power and cable infrastructure.

8 models

Electric underground LHD loader

TC-0.6E

0.6Bucket volume (m³)37Motor power (kW)

All specifications ＋

Rated load (t): 1.2
Bucket volume (m³): 0.6
Empty weight (t): 4.5
Shoveling force (kN): 42
Tractive force (kN): 45
Motor power (kW): 37
Full-load speed (km/h): 0–9.5
Length (mm): 4880
Width (mm): 1150
Height (mm): 1825

Product details →Enquire

Electric underground LHD loader

TC-1E

1Bucket volume (m³)45Motor power (kW)

All specifications ＋

Rated load (t): 2
Bucket volume (m³): 1
Empty weight (t): 7.5
Shoveling force (kN): 45
Tractive force (kN): 55
Motor power (kW): 45
Full-load speed (km/h): 0–9.5
Length (mm): 5710
Width (mm): 1405
Height (mm): 1920 (adjustable)

Product details →Enquire

Electric underground LHD loader

TC-0.75E

0.75Bucket volume (m³)37Motor power (kW)

All specifications ＋

Rated load (t): 1.5
Bucket volume (m³): 0.75
Empty weight (t): 7.3
Shoveling force (kN): 42
Tractive force (kN): 45
Motor power (kW): 37
Full-load speed (km/h): 0–9.5
Length (mm): 5570
Width (mm): 1250
Height (mm): 1920 (adjustable)

Product details →Enquire

Electric underground LHD loader

TC-1.5E

1.5Bucket volume (m³)75Motor power (kW)

All specifications ＋

Rated load (t): 3
Bucket volume (m³): 1.5
Empty weight (t): 11.6
Shoveling force (kN): 80
Tractive force (kN): 110
Motor power (kW): 75
Full-load speed (km/h): 0–12 (3 gears)
Length (mm): 6645
Width (mm): 1638
Height (mm): 2086

Product details →Enquire

Electric underground LHD loader

TC-2E

2Bucket volume (m³)75Motor power (kW)

All specifications ＋

Rated load (t): 4
Bucket volume (m³): 2
Empty weight (t): 13.8
Shoveling force (kN): 80
Tractive force (kN): 110
Motor power (kW): 75
Full-load speed (km/h): 0–12 (3 gears)
Length (mm): 7500
Width (mm): 1840
Height (mm): 1960

Product details →Enquire

Electric underground LHD loader

TC-410E

4Bucket volume (m³)110Motor power (kW)

All specifications ＋

Rated load (t): 8
Bucket volume (m³): 4
Empty weight (t): 23.5
Shoveling force (kN): 180
Tractive force (kN): 200
Motor power (kW): 110
Full-load speed (km/h): 0–15
Length (mm): 5710
Width (mm): 2325
Height (mm): 2320

Length is reproduced as 5,710 mm in the catalogue; confirm the overall drawing before selection.

Product details →Enquire

Electric underground LHD loader

TC-306E

3Bucket volume (m³)90Motor power (kW)

All specifications ＋

Rated load (t): 6
Bucket volume (m³): 3
Empty weight (t): 18.5
Shoveling force (kN): 100
Tractive force (kN): 150
Motor power (kW): 90
Full-load speed (km/h): 0–11 (4 gears)
Length (mm): 8550
Width (mm): 2150
Height (mm): 2057

Product details →Enquire

Electric underground LHD loader

TC-610E

6Bucket volume (m³)132Motor power (kW)

All specifications ＋

Rated load (t): 14
Bucket volume (m³): 6
Empty weight (t): 25
Shoveling force (kN): 220
Tractive force (kN): 240
Motor power (kW): 132
Full-load speed (km/h): 0–15
Length (mm): 10370
Width (mm): 2880
Height (mm): 2550

Product details →Enquire

Mining Trucks

Articulated underground trucks for mine haulage, with catalogue payloads from 6 to 40 tonnes.

8 models

Underground mining truck

TU-6

6Rated load (t)84Engine power (kW)

All specifications ＋

Rated load (t): 6
Body volume (m³): 3
Empty weight (t): 7.2
Tractive force (kN): 90
Engine power (kW): 84
Full-load speed (km/h): 0–18 (3 gears)
Length (mm): 6557
Width (mm): 1800
Height (mm): 2000

Product details →Enquire

Underground mining truck

TU-12

12Rated load (t)136Engine power (kW)

All specifications ＋

Rated load (t): 12
Body volume (m³): 6
Empty weight (t): 15
Tractive force (kN): 120
Engine power (kW): 136
Full-load speed (km/h): 0–20 (4 gears)
Length (mm): 7678
Width (mm): 2070
Height (mm): 2400

Product details →Enquire

Underground mining truck

TU-8

8Rated load (t)115Engine power (kW)

All specifications ＋

Rated load (t): 8
Body volume (m³): 4
Empty weight (t): 12
Tractive force (kN): 120
Engine power (kW): 115
Full-load speed (km/h): 0–20 (4 gears)
Length (mm): 7500
Width (mm): 1900
Height (mm): 2400

Product details →Enquire

Underground mining truck

TU-16

16Rated load (t)165Engine power (kW)

All specifications ＋

Rated load (t): 16
Body volume (m³): 8
Empty weight (t): 18
Tractive force (kN): 130
Engine power (kW): 165
Full-load speed (km/h): 0–20 (4 gears)
Length (mm): 7978
Width (mm): 2250
Height (mm): 2410

Product details →Enquire

Underground mining truck

TU-10

10Rated load (t)136Engine power (kW)

All specifications ＋

Rated load (t): 10
Body volume (m³): 5
Empty weight (t): 14.5
Tractive force (kN): 120
Engine power (kW): 136
Full-load speed (km/h): 0–20 (4 gears)
Length (mm): 7500
Width (mm): 2000
Height (mm): 2400

Product details →Enquire

Underground mining truck

TU-40

40Rated load (t)405Engine power (kW)

All specifications ＋

Rated load (t): 40
Body volume (m³): 20
Empty weight (t): 36
Tractive force (kN): 400
Engine power (kW): 405
Length (mm): 10410
Width (mm): 3070
Height (mm): 2810

Product details →Enquire

Underground mining truck

TU-20

20 (22)Rated load (t)235 (242)Engine power (kW)

All specifications ＋

Rated load (t): 20 (22)
Body volume (m³): 10 (11)
Empty weight (t): 20.5
Tractive force (kN): 200
Engine power (kW): 235 (242)
Full-load speed (km/h): 0–24
Length (mm): 9205
Width (mm): 2400
Height (mm): 2530

Product details →Enquire

Underground mining truck

TU-30

30Rated load (t)315Engine power (kW)

All specifications ＋

Rated load (t): 30
Body volume (m³): 15
Empty weight (t): 31
Tractive force (kN): 320
Engine power (kW): 315
Length (mm): 9930
Width (mm): 2800
Height (mm): 2560

Product details →Enquire

Utility Vehicles

Purpose-built vehicles for personnel, materials, maintenance, fuel, lifting and specialist underground tasks.

13 models

Underground excavating service vehicle

TPXW-104

7Empty weight (t)55Engine power (kW)

All specifications ＋

Empty weight (t): 7
Engine power (kW): 55
Full-load speed (km/h): 0–9.5
Length (mm): 6660
Width (mm): 1250
Height (mm): 2000

Product details →Enquire

Elevating service platform

TFS-6

0.3Rated load (t)96Engine power (kW)

All specifications ＋

Rated load (t): 0.3
Empty weight (t): 8.5
Tractive force (kN): 70
Engine power (kW): 96
Full-load speed (km/h): 0–18 (3 gears)
Length (mm): 7663
Width (mm): 1600
Height (mm): 2029

Product details →Enquire

Underground road grader

TPD-1

7Empty weight (t)55Engine power (kW)

All specifications ＋

Empty weight (t): 7
Engine power (kW): 55
Full-load speed (km/h): 0–9.5
Length (mm): 5740
Width (mm): 1250
Height (mm): 1920

Product details →Enquire

Boom-type elevating platform

TCS-2

0.3Rated load (t)84Engine power (kW)

All specifications ＋

Rated load (t): 0.3
Tractive force (kN): 100
Engine power (kW): 84
Full-load speed (km/h): 0–20 (4 gears)
Length (mm): 7620
Width (mm): 1607
Height (mm): 1960

Product details →Enquire

Underground maintenance vehicle

TFW-3

3Rated load (t)63Engine power (kW)

All specifications ＋

Rated load (t): 3
Empty weight (t): 7.3
Tractive force (kN): 80
Engine power (kW): 63
Full-load speed (km/h): 0–18 (3 gears)
Length (mm): 6500
Width (mm): 1800
Height (mm): 2300

Product details →Enquire

Mobile fuel service vehicle

TFY-5

5Rated load (t)84Engine power (kW)

All specifications ＋

Rated load (t): 5
Empty weight (t): 8.5
Tractive force (kN): 90
Engine power (kW): 84
Full-load speed (km/h): 0–20
Length (mm): 6800
Width (mm): 1800
Height (mm): 2000

Product details →Enquire

Underground generator vehicle

TFF-5

5Rated load (t)84Engine power (kW)

All specifications ＋

Rated load (t): 5
Empty weight (t): 12
Tractive force (kN): 90
Engine power (kW): 84
Full-load speed (km/h): 0–20
Length (mm): 6800
Width (mm): 1800
Height (mm): 2000
Generator capacity (kW): 300

Product details →Enquire

Lubricant transport vehicle

TFFY-5

5Rated load (t)84Engine power (kW)

All specifications ＋

Rated load (t): 5
Empty weight (t): 8.5
Tractive force (kN): 90
Engine power (kW): 84
Full-load speed (km/h): 0–20
Length (mm): 6800
Width (mm): 1800
Height (mm): 2000

Product details →Enquire

Bulk cement transport vehicle

TFW-5

5Rated load (t)84Engine power (kW)

All specifications ＋

Rated load (t): 5
Empty weight (t): 7.5
Tractive force (kN): 90
Engine power (kW): 84
Full-load speed (km/h): 0–20
Length (mm): 6800
Width (mm): 1800
Height (mm): 2300

Product details →Enquire

Personnel transport vehicle · up to 25 people

TFR-25

5Rated load (t)84Engine power (kW)

All specifications ＋

Rated load (t): 5
Empty weight (t): 7.5
Tractive force (kN): 90
Engine power (kW): 84
Full-load speed (km/h): 0–20
Length (mm): 6800
Width (mm): 1800
Height (mm): 2300

Product details →Enquire

Material transport vehicle

TFY-5 (Materials)

5Rated load (t)84Engine power (kW)

All specifications ＋

Rated load (t): 5
Empty weight (t): 7.2
Tractive force (kN): 90
Engine power (kW): 84
Full-load speed (km/h): 0–20
Length (mm): 6560
Width (mm): 800
Height (mm): 2000

The material transport variant is also labelled TFY-5 in the catalogue. Its printed width is 800 mm; confirm the overall drawing.

Product details →Enquire

Underground charging vehicle

TFY-6

6Rated load (t)96Engine power (kW)

All specifications ＋

Rated load (t): 6
Empty weight (t): 9
Tractive force (kN): 70
Engine power (kW): 96
Full-load speed (km/h): 0–18
Length (mm): 7124
Width (mm): 1600
Height (mm): 2266

Product details →Enquire

Rock sampling vehicle

TPK-1

7.1Empty weight (t)55Engine power (kW)

All specifications ＋

Empty weight (t): 7.1
Tractive force (kN): 55
Engine power (kW): 55
Full-load speed (km/h): 0–9.5
Length (mm): 6120
Width (mm): 1300
Height (mm): 1920
Sampling height (m): 0.5–1.8
Sampling depth (mm): 0–100

English column labels are misaligned in the catalogue; parameters follow the Chinese labels.

Product details →Enquire

Rock Breaking & Scaling

Mobile and stationary breakers, plus scaling equipment for underground development.

5 models

Underground scaling vehicle

TPX-104

7Machine weight (t)55Engine power (kW)

All specifications ＋

Machine weight (t): 7
Hammer rod diameter (mm): 45
Engine power (kW): 55
Full-load speed (km/h): 0–9.5
Length (mm): 6635
Width (mm): 1250
Height (mm): 1920 (adjustable)

Product details →Enquire

Mobile rock breaker

TP-8

7.6Machine weight (t)55Engine power (kW)

All specifications ＋

Machine weight (t): 7.6
Hammer rod diameter (mm): 68–100
Engine power (kW): 55
Full-load speed (km/h): 0–9.5
Length (mm): 6170
Width (mm): 1250
Height (mm): 1920

Product details →Enquire

Mobile rock breaker

TXP-12

14Machine weight (t)84Engine power (kW)

All specifications ＋

Machine weight (t): 14
Hammer rod diameter (mm): 118
Engine power (kW): 84
Full-load speed (km/h): 0–18 (3 gears)
Length (mm): 9400
Width (mm): 1810
Height (mm): 2530 (2930)

Product details →Enquire

Mobile rock breaker

TP-10

7.8Machine weight (t)55Engine power (kW)

All specifications ＋

Machine weight (t): 7.8
Hammer rod diameter (mm): 68–85
Engine power (kW): 55
Full-load speed (km/h): 0–9.5
Length (mm): 7100
Width (mm): 1300
Height (mm): 1920

Product details →Enquire

Stationary rock breaker

TPG-9

14Machine weight (t)45Motor power (kW)

All specifications ＋

Machine weight (t): 14
Hammer rod diameter (mm): 118
Motor power (kW): 45
Supply voltage (V): 380

Product details →Enquire

Technical values follow the supplied Tuoxing equipment catalogue. Figures in parentheses are retained as printed. Final configuration and dimensional drawings are confirmed for each order.

Custom equipment & specialist support

When your site needs a different approach.

01 / CUSTOM MACHINES

Configured to the application

The catalogue also presents custom 2D, 3.5D, 307, 410 and 514 loaders, plus 2010 and 2020 trucks. Dimensions, powertrain and capacities are specified for the project.

02 / CONNECTED OPERATIONS

Remote control enquiries

Discuss remote operation and underground wireless network requirements. Equipment compatibility, network coverage and implementation scope require a site review.

03 / COMPONENTS

Structural & mechanical parts

Enquire about buckets, frames, mechanical assemblies and replacement components. Send drawings, machine references and quantities to establish the specification.

Discuss a custom requirement →

Mechanical axle assemblies from the product catalogue

Spare parts

Parts that fit your requirements.

Mechanical and structural components for underground mining equipment. Share your model, part number or drawing so we can help confirm the specification.

Share requirements

Model, part number
or drawing.

Confirm specifications

Review configuration
and compatibility.

Receive quotation

Clarify price and
supply terms.

Get in touch

Start with your site. We’ll help with the specification.

✉ info@unibesco.com Request a Quote

Support Around Your Operation

From the first specification to parts and overhaul enquiries, start with your equipment details and operating requirements. Email info@unibesco.com to discuss the available options.

Overhaul Enquiries

Equipment Selection

Customization & Parts

Built for the demands below.

Choose the equipment. Define the possibilities.

Diesel LHD Loaders

Electric LHD Loaders

Underground Mining Trucks

From the working faceto the next shift.

Load & haul

Develop & support

Maintain & renew

Every task. The right specification.

Diesel LHD Loaders

TC-0.6

TC-0.6CB

TC-0.75

TC-0.6C

TC-1A

TC-1CB

TC-1C

TC-2C

TC-200CF

TC-300

TC-306

TC-200D

TC-614

TC-307

TC-410

Electric LHD Loaders

TC-0.6E

TC-1E

TC-0.75E

TC-1.5E

TC-2E

TC-410E

TC-306E

TC-610E

Mining Trucks

TU-6

TU-12

TU-8

TU-16

TU-10

TU-40

TU-20

TU-30

Utility Vehicles

TPXW-104

TFS-6

TPD-1

TCS-2

TFW-3

TFY-5

TFF-5

TFFY-5

TFW-5

TFR-25

TFY-5 (Materials)

TFY-6

TPK-1

Rock Breaking & Scaling

TPX-104

TP-8

TXP-12

TP-10

TPG-9

When your site needs a different approach.

Configured to the application

Remote control enquiries

Structural & mechanical parts

Parts that fit your requirements.

Start with your site. We’ll help with the specification.

From the working face
to the next shift.
